Darcor

Medium/Heavy-Duty Caster, Rigid, 3" (76 mm), Solid Elastomer, 500 lbs. (227 kg.)

Model: MG302

Mfr. No.: 31-73R-PSE

  • Medium/Heavy-Duty Caster, Rigid, 3" (76 mm), Solid Elastomer, 500 lbs. (227 kg.) Seaboard Timber Mart

Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

$72.80 / Each

Wheel Diameter

3" (76 mm)

Capacity

500 lbs. (227 kg.)

Wheel Material

Solid Elastomer

Caster Type

Rigid

Frame Material

Steel

Tread Width

1-3/8" (35 mm)

Bolt Hole Spacing

2-5/8" - 3" (67 mm x 76 mm) - 3" - 3-5/8" (76 mm - 92 mm)

Bolt Hole Size

3/8" (9.52 mm)

Plate Size

4" x 4-1/2" (102 mm x 114 mm)

Bearing Type

Precision Ball

Swivel Radius

3"

Overall Height

4.625"

  • 9/16" rivet
  • 3/8" axle
  • Thread guards standard on wheels
  • Double row ball bearing swivel; both raceways equal diameter
  • All swivel parts case hardened to Rockwell 62C
  • Bright zinc finish
  • Brake available on 4", 5" and 6" diameter wheels ; Excellent for:
  • Material handling carts
  • Institutional equipment
